Product Line Induction Range
Power Type Electric 240v
Size 30"
Installation Type Free-Standing
Factory Springfield
Color Stainless Steel
Cooktop
Auto Pan Detect Yes
Bridge Element Location Left
Cooking Surface Type Smooth
Hot-Surface Indicator Light Yes
Cooktop Performance
Right Front Element Burner Size 8 3/10"
Right Rear Element Burner Size 5 1/2"
Left Front Element Burner Size 7"
Left Rear Element Burner Size 7"
Right Front Element Burner 2,300 / 3,600 Watts (Boost)
Right Rear Element Burner 1,400 / 2,500 Watts (Boost)
Left Front Element Burner 1,800 / 2,800 Watts (Boost)
Left Rear Element Burner 1,800 / 2,800 Watts (Boost)
Cooking Controls
Bake Yes
Bake Time Yes
Broil Yes
Cancel Yes
Child Lock Yes
Clock Yes
Convection Bake Yes
Cook Time Yes
Delay Clean Yes
Delay Start Yes
Door Lock Yes
Hot Surface Yes
Keep Warm Yes
Kitchen Timer Yes
Light Yes
Lockout Yes
Off Yes
On / Off (for each element) Yes
Oven Light Yes
Preheat Yes
Probe No
Self Clean Yes
Set Clock Yes
Start Yes
Temperature Display Yes
Timer On / Off Yes
User Preferences Yes
Oven
Bake Element 2500 Watts
Bake Element Pass 8
Bake Element Type Hidden
Broil Element 4000 Watts
Broil Element Pass 6
Cleaning System Yes
Convection Yes
Convection Type Fan
Number of Convection Fans 1
Number of Rack Positions 6
Oven Interior Color Midnight Black
Oven Light Quantity 1
Oven Light Type Halogen
Oven Light Watts 40 Watts
Rack Position Type Embossed
Rack Type 1 Flat
Rack Type 1 Quantity 2
Drawer
Drawer Type Storage
Controls
Control Lock Yes
Display
Control Location Front
Display Interface Color White
Display Type Capacitive Touch
Dimensions and Volume
Minimum Height 35 3/8"
Maximum Height 36 3/8"
Width 30"
Depth 26"
Depth With Door 90° Open 47 5/16"
Depth With Handle 28 1/2"
Oven Interior Height 18 1/8"
Oven Interior Width 25 3/16"
Oven Interior Depth 19 7/8"
Oven Capacity 5.3 Cu. Ft.
Electrical Specifications
Connected Load @ 240V 15 kW
Minimum Circuit Required 40 Amps
Voltage Rating 240 V
Installation
Adjustable Leveling Legs Yes
Power Cord Included Yes
General Specifications
Frigidaire Fit Promise Yes
Product Weight 162 lbs
Prop 65 Label Yes
Warranty - Labor 1 Year
Warranty - Parts 1 Year
Certifications and Approvals
ADA Compliant Yes
UL Listed Yes
cUL Listed Yes
RoHS Yes
